GWH09AFC-D3DNA1A/O
Product Code CB348W03400
1 Front Grill 01473012 1
2 Front Panel Assy 0153304804 1
3 Axial Flow Fan 10333004 1
4 Chassis Sub-assy 017000060337P 1
5 Clapboard Sub-Assy 0123338502 1
6 Drainage Connecter 06123401 1
7 Compressor Gasket 009012000027 3
8 4-Way Valve Assy 030152060316 1
9 Valve Support 0171314201P 1
10 Cut off Valve Assy 07133474 1
11 Valve 07100003 1
12 Valve Support Block 26113017 2
13 Cover of Pass Wire 01413069 1
14 Right Side Plate Assy 013030713 1
15 Cable Cross Plate 2 02123014P 1
16 Magnet Coil 4300040050 1
17 Electric Expansion Valve Sub-Assy 030026060292 1
18 Rear Grill 01473009 1
19 Electric Box 2011303401 1
20 Main Board 300027060725 1
21 Reactor 43130184 1
22 Electric Box Assy 100002064985 1
23 Terminal Board 422000060016 1
24 Wire Clamp 71010003 1
25 Top Cover Sub-Assy 01253108P 1
26 Condenser Assy 011002060611 1
27 Motor Support 0170310403 1
28 Fan Motor 1501308511 1
29 Compressor Overload Protector(External) 00180030 1
30 Compressor and Fittings 009001060050 1
31 Small Handle 26233100 1
32 Temperature Sensor 3900030805
1
33 valve cover 2012300101 1
