Installation and Maintenance
Service Manual
No.
Description
Part Code
QtyGWH18QD-D3DNC6L/O GWH24QE-D3DNC6O/O
Product Code CB443W04800 CB443W05000
1 Front Grill 01473049 01473049 1
2 Cabinet 01433047P 01433047P 1
3 Axial Flow Fan 10335008 10335008 1
4 Fan Motor 1501506402 1501506402 1
5 Chassis Sub-assy 01700000093P 01700000161P 1
6 Drainage hole Cap 06813401 06813401 3
7 Clapboard Assy 01233153 01235081 1
8 4-Way Valve Assy 030152000291 030152000073 1
9 Compressor and Fittings 00105249G 00105249G 1
10 Valve Support Assy 01715010P 01705046 1
11 Cut off Valve 07130239 07133844 1
12 Cut off Valve Sub-Assy 07133204 07133843 1
13 Right Side Plate 0130509403P 0130509002P 1
14 Valve Cover 22245002 22245002 1
15 Retaining Plate 02115006P 02115006P 1
16 Handle Assy 02113109 02113109 1
17 Valve Support Block / 26115007 1
18 Temperature Sensor 3900030901 3900030902 1
19 Rear Grill 01473043 01475020 1
20 Condenser Assy 011002000513 011002000244 1
21 Coping 012049000007P 012049000007P 1
22 Motor Support Sub-Assy 01703154 01705067 1
23 Condenser Support Plate 01173127 01795031 1
24 Left Side Plate 01305093P 01305093P 1
25 Handle 26233053 26233053 1
26 Electric Box Assy 100002001525 100002001406 1
27 Terminal Board 42010255 42010255 1
28 Electric Box 20113027 20113027 1
29 Main Board 300027000297 300027000301 1
30 Radiator 49013076/49013060 49013076/49013060 1
31 Electronic Expansion Valve assy 030026000208 030174000041 1
Above data is subject to change without notice.
