165
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWH24AFE-D3DNA1A/O
Product Code CB348W03100
1 Front Grill 016004000006 1
2 Cabinet 01433047P 1
3 Axial Flow Fan 10335008 1
4 Fan Motor 1501506402 1
5 Chassis Sub-assy 017000060297P 1
6 Drainage hole Cap 06813401 1
7 Clapboard Assy 01233153 1
8 4-Way Valve Assy 030152060325 1
9 Compressor and Fittings 00900100019501 1
10 Valve Support Assy 01705046P 1
11 Cut off Valve 07130239 1
12 Cut off Valve Sub-Assy 07133843 1
13 Right Side Plate 0130509403P 1
14 Valve Cover 22245002 1
15 Retaining Plate 02115006P 1
16 Handle Assy 02113109 1
17 Valve Support Block 26113017 1
18 Temperature Sensor 3900030901 1
19 Rear Grill 01473043 1
20 Condenser Assy 011002060552 1
21 Coping 012049000007P 1
22 Motor Support Sub-Assy 01705067 1
23 Condenser Support Plate 01795010 1
24 Left Side Plate 01305093P 1
25 Handle 26233053 1
26 Electric Box Assy 100002064488 1
27 Terminal Board 42200006001401 1
28 Electric Box 2011302701 1
29 Main Board 300027060610 1
30 Radiator 49010252/49013060 1/1
31 Electronic Expansion Valve assy 030174060060 1
To Next Page
