16
Technical Information
Service Manual
Model GWH12QC-D3DND8A
Product Code CB459007000
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 12000
Heating Capacity Btu/h 13000
Cooling Power Input W 1089
Heating Power Input W 1126
Cooling Power Current A 4.73
Heating Power Current A 4.90
Rated Input W 1600
Rated Current A 6.6
Air Flow Volume(SH/H/M/L/SL) CFM 371/294/235/182/-
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 11.0
COP (Btu/h)/W 11.55
SEER 20
HSPF 9.1
Application Area yd
2
19.1-28.7
Indoor Unit
Model of indoor unit GWH12QC-D3DND8A/I
Indoor Unit Product Code CB459N07000
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 55/64X25
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1350/1200/1050/850
Fan Motor Heating Speed (SH/H/M/L/SL) r/min 1300/1150/1000/900
Output of Fan Motor W 20
Fan Motor RLA A 0.31
Fan Motor Capacitor μF 1.5
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 25X57/64X12 3/64
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L/SL) dB (A) 42/39/35/39/-
Sound Power Level (SH/H/M/L/SL) dB (A) 52/49/45/39/-
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11X15
Net Weight Ib 23.2
Gross Weight Ib 27.6
