17
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit GWH12AFC-D3DNA1A/O
Outdoor Unit Product Code CB348W03600
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD
Compressor Model QXF-A102zE190B
Compressor Oil FW68DA
Compressor Type Rotary
Compressor L.R.A. A /
Compressor RLA 6.6
Compressor Power Input W 1023
Overload Protector HPC115/95U1/KSD115ºC
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF -4~115
Ambient temp (heating) ºF -13~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/8
Rows-n Gap inch 2-1/16
Coil Length (LXDXW) inch 29 13/32X1 3/4X22
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.37
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 1295
Fan Type Axial-ow
Fan Diameter inch Φ17 1/4
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Design Pressure(High) PSIG 550
Design Pressure(Low) PSIG 240
Sound Pressure Level (H/M/L) dB (A) 53/-/-
Sound Power Level (H/M/L) dB (A) 63/-/-
Dimension (WXHXD) inch 33 25/64X23 15/32X12 19/32
Dimension of Carton Box (LXWXH) inch 34 9/16X14 11/64X24 51/64
Dimension of Package (LXWXH) inch 34 11/16X14 19/64X25 25/64
Net Weight Ib 72.8
Gross Weight Ib 79.4
Refrigerant R410A
Refrigerant Charge oz 35.3
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 3/8
Max Distance Height ft 40
Max Distance Length ft 65.6
Note:The connection pipe applies metric diameter.
