18
Technical Information
Service Manual
Model
1.GWC24QE-D3DND8C 2.GWC24QE-D3DNB2C
3.GWC24QE-D3DNC2C 4.GWC24QE-D3DND4C
Product Code
1.CB459006800 2.CB432023500
3. CB439015100 4.CB464003000
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 22000
Heating Capacity Btu/h /
Cooling Power Input W 1870
Heating Power Input W /
Cooling Power Current A 8.1
Heating Power Current A /
Rated Input W 2860
Rated Current A 12.5
Air Flow Volume(SH/H/M/L/SL) CFM 765/677/588/500/-
Dehumidifying Volume Pint/h 4.23
EER (Btu/h)/W 11.76
COP (Btu/h)/W /
SEER 19
HSPF /
Application Area yd
2
27.5-40.7
Indoor Unit
Model of indoor unit
1.GWC24QE-D3DND8C/I 2.GWC24QE-D3DNB2C/I
3.GWC24QE-D3DNC2C/I 4.GWC24QE-D3DND4C/I
Indoor Unit Product Code
1.CB459N06800 2.CB432N23500
3.CB439N15100 4.CB464N03000
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 16/64×32 43/64
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1300/1150/1000/850/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min /
Output of Fan Motor W 30
Fan Motor RLA A 0.32
Fan Motor Capacitor μF 3
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ5/16
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 33 30/64×1×13 30/64
Swing Motor Model MP35CJ
Output of Swing Motor W 2.5
Fuse A 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) Cooling:49/45/41/37
Sound Power Level (SH/H/M/L/SL) dB (A) Cooling:59/55/51/47
Dimension (WXHXD) inch 42 7/16X12 13/16X9 11/16
Dimension of Carton Box (LXWXH) inch 45X16 1/8X13 3/16
Dimension of Package (LXWXH) inch 45 3/16X16 1/4X13 3/4
Net Weight
Ib 36.4
Gross Weight Ib 44.1
