Technical Information
Service Manual
Model
1.GWC18QD-D3DND8A 2.GWC18QD-D3DNB2C
3.GWC18QD-D3DNC2A 4.GWC18QD-D3DND4A
Product Code
1.CB459007200 2.CB432023300
3.CB439015500 4.CB464003300
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 17400
Heating Capacity Btu/h /
Cooling Power Input W 1730
Heating Power Input W /
Cooling Power Current A 7.1
Heating Power Current A /
Rated Input W 2000
Rated Current A 10.5
Air Flow Volume(SH/H/M/ML/L) CFM 530/441/412/335/-
Dehumidifying Volume Pint/h 3.8
EER (Btu/h)/W 10.1
COP (Btu/h)/W /
SEER 20
HSPF /
Application Area yd
2
27.5-40.7
Indoor Unit
Model of indoor unit
1.GWC18QD-D3DND8A/I 2.GWC18QD-D3DNB2C/I
3.GWC18QD-D3DNC2A/I 4.GWC18QD-D3DND4A/I
Indoor Unit Product Code
1.CB459N07200 2.CB432N23300
3.CB439N15500 4.CB464N03300
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 3/16X27 13/16
Fan Motor Cooling Speed (SH/H/M/ML/L) r/min 1400/1200/1050/800/-
Fan Motor Heating Speed (SH/H/M/ML/L) r/min /
Output of Fan Motor W 60
Fan Motor RLA A 0.3
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ 9/32
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 28 1/6X1X12
Swing Motor Model MP35CJ
Output of Swing Motor W 2.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/ML/L) dB (A) 47/42/38/31/-
Sound Power Level (SH/H/M/ML/L) dB (A) 57/52/48/41/-
Dimension (WXHXD) inch 38 3/16X11 13/16X8 13/16
Dimension of Carton Box (LXWXH) inch 40 7/8X15X12
Dimension of Package (LXWXH) inch 41X15X12 5/8
Net Weight Ib 29.8
Gross Weight Ib 36.4
