Outdoor Unit
Model of Outdoor Unit GWC18AFD-D3DNA1A/O
Outdoor Unit Product Code CB348W04700
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO. LTD.
Compressor Model QXF-A102zE190C
Compressor Oil FW68DA or equivalent
Compressor Type Rotary
Compressor L.R.A. A 25
Compressor RLA 8.5
Compressor Power Input W 1023
Overload Protector 1NT11L-6233/KSD115ºC/HPC 115/95
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF -4~115
Ambient temp (heating) ºF /
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Rows-n Gap inch 2-1/16
Coil Length (LXDXW) inch 28 9/10X1 1/2X21 7/10
Fan Motor Speed rpm 880
Output of Fan Motor W 40
Fan Motor RLA A 0.62
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 1412
Fan Type Axial-ow
Fan Diameter inch Φ17 33/64
Defrosting Method /
Climate Type T1
Isolation I
Moisture Protection IPX4
Design Pressure(High) PSIG 550
Design Pressure(Low) PSIG 240
Sound Pressure Level (H/M/L) dB (A) 52/-/-
Sound Power Level (H/M/L) dB (A) 62/-/-
Dimension (WXHXD) inch 35 3/8X23 1/2X14 7/8
Dimension of Carton Box (LXWXH) inch 37 3/16X16 7/16X24 13/16
Dimension of Package (LXWXH) inch 37 5/16X16 9/16X25 3/8
Net Weight Ib 80.5
Gross Weight Ib 87.1
Refrigerant R410A
Refrigerant Charge oz 37
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 1/2
Max Distance Height ft 50
Max Distance Length ft 100
Note:The connection pipe applies metric diameter.
