54
Technical Information
Service Manual
● Top view
● Bottom view
1234
6
10
7
8
913
11
12
5
No.Name
1Neutral wire
2Needle stand for indoor fan
3Auto button
4Up&down swing motor
5
6Interface of temperature sensor
7
Terminal for display board
connection
8Terminal of jumper cap
9Communication wire
10
11 Fuse
12 Live wire interface
13 Detecting plate(WIFI )
Grounding wire
Terminal of wired controlle
GWH07QC-D3DNB2D/I GWC18QD-D3DNB2C/I GWC18QD-D3DNC2A/I GWC18QD-D3DND4A/I
GWC18QD-D3DND8A/I
