55
Technical Information
Service Manual
GWC09QC-D3DND8C/I GWH09QC-D3DND8A/I GWC12QC-D3DND8C/I GWH12QC-D3DND8A/I GWC24QE-D3DND8C/I
GWH24QE-D3DND8A/I GWC09QC-D3DNB2C/I GWC09QC-D3DNC2C/I GWC09QC-D3DND4C/I GWC12QC-D3DNB2C/I
GWC12QC-D3DNC2C/I GWC12QC-D3DND4C/I GWC24QE-D3DNB2C/I GWC24QE-D3DNC2C/I GWC24QE-D3DND4C/I
No Name
1
2
3
Interface of live wire
Fuse
4
Interface of neutral wire
5
Interface of fan
6
7
8
Auto button
Interface of wifi
9
Up&down swing interface
Interface of PG feedback
Interface of gate-control
10
11
12
Needle stand for tube temperature
sensor
Display interface
14
15
16
Jump
Terminal with indoor unit communication wire
Interface of health function neutral wire
Interface of health function live wire
17
Left&right swing interface
Wired controller (only for the mode with this
function)
13
1
2
413 41 5567
8
9
10
16
111213
17
To Next Page
