Technical Information
Service Manual
GWC09QB-D3DNB2J/O GWH09QB-D3DNB2J/O
3
9
2
4
5
8 7 61011
1
No. Name
1 Compressor three phase input interface
2 Interface of fan
3 Interface of electric heating for chassis
4 4-way valve interface
5
6
Interface of earthing wire
7 Neutral wire
Interface of live wire
8
9
Communication interface
10
Compressor overload protection
interface
Needle stand of electronic expansion
valve
11 Interface of temperature sensor
● Top view
● Bottom view
