9
Technical Information
Service Manual
Outdoor Unit
Outdoor Unit Model
GWH24MD-D3DNA3D/O
(electric heating band)
GWH24MD-D3DNA3D/O
Outdoor Unit Product Code CB171W07001 CB171W07000
Compressor Manufacturer
MITSUBISHI ELECTRIC
(GUANGZHOU)COMPRESSOR
CO. LTD
MITSUBISHI ELECTRIC
(GUANGZHOU)COMPRESSOR
CO. LTD
Compressor Model SNB150FGAMC SNB150FGAMC
Compressor Oil PVE/FV50S PVE/FV50S
Compressor Type Rotary Rotary
Compressor LRA. A 18.50 18.50
Compressor RLA A 4.90 4.90
Compressor Power Input W 1420 1420
Compressor Overload Protector 1NT11L-6578 1NT11L-6578
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range °F 61~86 61~86
Cooling Operation Ambient Temperature
Range
°F 19.4~109 19.4~109
Heating Operation Ambient Temperature
Range
°F 19.4~75.2 19.4~75.2
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter inch Φ2/7 Φ2/7
Condenser Rows-n Gap inch 2-1/18 2-1/18
Condenser Coil Length (LXDXW) inch 38X1 1/2X29 4/9 38X1 1/2X29 4/9
Fan Motor Speed rpm 800 800
Fan Motor Power Output W 90 90
Fan Motor RLA A 1.1 0.5
Fan Motor Capacitor μF 4 /
Outdoor Unit Air Flow Volume CFM 2354 2354
Fan Type Axial-ow Axial-ow
Fan Diameter inch 20 3/4 Φ21 3/4
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure
for the Discharge Side
PSIG 550 550
Permissible Excessive Operating Pressure
for the Suction Side
PSIG 450 240
Sound Pressure Level (H/M/L) dB (A) 58/-/- 58/-/-
Sound Power Level (H/M/L) dB (A) 68/-/- 68/-/-
Dimension (WXHXD) inch 38 4/7X31 1/9X16 4/5 38 4/7X31 1/9X16 4/5
Dimension of Carton Box (LXWXH) inch 42 1/2X19X33 42 1/2X19X33
Dimension of Package (LXWXH) inch 42 2/3X19 1/5X33 2/3 42 2/3X19 1/5X33 2/3
Net Weight lb 132.3 123.3
Gross Weight lb 145.5 143.3
Refrigerant R410A R410A
Refrigerant Charge oz 56.4 56.4
Connection
Pipe
Connection Pipe Length ft 24 3/5 24 3/5
Connection Pipe Gas Additional Charge oz/ft. 0.5 0.5
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 5/8 5/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 82 82
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
