Gree GWC18MC-D3DNA3F/I User Manual

8
Technical Information
Service Manual
Model
GWH24MD-D3DNA3F
GWH24MD-D3DNA5F
GWH24MD-D3DNA3F
GWH24MD-D3DNA8F
Product Code
CB171009801
CB162009501
CB171009800
CB173005000
Power
Supply
Rated Voltage V
～
208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min
～
Max) Btu/h 21400(9600~25000) 21400(9600~25000)
Heating Capacity(Min
～
Max) Btu/h 23000(4300~26000) 23000(4300~26000)
Cooling Power Input(Min
～
Max) W 1780(500~2650) 1780(500~2650)
Heating Power Input(Min
～
Max) W 2100(400~2750) 2100(400~2750)
Cooling Current Input A 7.9 7.9
Heating Current Input A 9.3 9.3
Rated Input W 2750 2750
Rated Current A 12.20 12.20
Air Flow Volume (S/H/M/L) CFM 589/471/412/353 589/471/412/353
Dehumidifying Volume Pint/h 5.28 5.28
EER (Btu/h)/W 12.0 12.0
COP (Btu/h)/W 10.6 10.6
SEER 18 18
HSPF 10 10
Application Area yd2 32 2/7-50 1/4 32 2/7-50 1/4
Indoor Unit
Indoor Unit Model
GWH24MD-D3DNA3F/I
GWH24MD-D3DNA5F/I
GWH24MD-D3DNA3F/I
GWH24MD-D3DNA8F/I
Indoor Unit Product Code
CB171N09800
CB162N09500
CB171N09800
CB173N05000
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) inch Φ3 6/7X30/1/8 Φ3 6/7X30/1/8
Cooling Speed(S/H/M/L) r/min 1500/1200/1050/900 1500/1200/1050/900
Heating Speed(S/H/M/L) r/min 1450/1150/1020/950 1450/1150/1020/950
Fan Motor Power Output W 60 60
Fan Motor RLA A 0.24 0.24
Fan Motor Capacitor μF / /
Evaporator Form W Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter inch Φ2/7 Φ2/7
Evaporator Row-n Gap inch 2-1/17 2-1/17
Evaporator Coil Length (LXDXW) inch 30 1/8X1X13 1/2 30 1/8X1X13 1/2
Swing Motor Model MP35XX MP35XX
Swing Motor Power Output W 3 3
Fuse Current A 3.15 3.15
Sound Pressure Level (S/H/M/L) dB (A) 53/45/41/37 53/45/41/37
Sound Power Level (S/H/M/L) dB (A) 63/55/51/47 63/55/51/47
Dimension (WXHXD) inch 39 2/3X12 2/5X8 5/8 39 2/3X12 2/5X8 5/8
Dimension of Carton Box (LXWXH) inch 42 1/4X15 5/9X12 1/3 42 1/4X15 5/9X12 1/3
Dimension of Package (LXWXH) inch 42 1/3X15 2/3X12 21/23 42 1/3X15 2/3X12 21/23
Net Weight lb 29.8 29.8
Gross Weight lb 37.5 37.5

Gree GWC18MC-D3DNA3F/I Specifications

General

Brand	Gree
Model	GWC18MC-D3DNA3F/I
Category	Air Conditioner
Language	English
