7
Technical Information
Service Manual
Outdoor Unit
Outdoor Unit Model GWC24MD-D3DNA3D/O
Outdoor Unit Product Code CB171W06900
Compressor Manufacturer
MITSUBISHI ELECTRIC (GUANGZHOU)
COMPRESSOR CO. LTD
Compressor Model SNB150FGAMC
Compressor Oil PVE/FV50S
Compressor Type Rotary
Compressor LRA. A 18.50
Compressor RLA A 4.90
Compressor Power Input W 1420
Compressor Overload Protector 1NT11L-6578
Throttling Method Electron expansion valve
Set Temperature Range °F 61~86
Cooling Operation Ambient Temperature Range °F 19.4~109
Heating Operation Ambient Temperature Range °F /
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter inch Φ2/7
Condenser Rows-n Gap inch 2-1/18
Condenser Coil Length (LXDXW) inch 38X1 1/2X29 4/9
Fan Motor Speed rpm 800
Fan Motor Power Output W 90
Fan Motor RLA A 1.1
Fan Motor Capacitor μF 4
Outdoor Unit Air Flow Volume CFM 2354
Fan Type Axial-ow
Fan Diameter inch 20 3/4
Defrosting Method /
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating Pressure for the
Discharge Side
PSIG 550
Permissible Excessive Operating Pressure for the Suction
Side
PSIG 450
Sound Pressure Level (H/M/L) dB (A) 58/-/-
Sound Power Level (H/M/L) dB (A) 68/-/-
Dimension (WXHXD) inch 38 4/7X31 1/9X16 4/5
Dimension of Carton Box (LXWXH) inch 42 1/2X19X33
Dimension of Package (LXWXH) inch 42 2/3X19 1/5X33 2/3
Net Weight lb 119.1
Gross Weight lb 130.1
Refrigerant R410A
Refrigerant Charge oz 56.4
Connection
Pipe
Connection Pipe Length ft 24 3/5
Connection Pipe Gas Additional Charge oz/ft. 0.5
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 5/8
Max Distance Height ft 32.8
Max Distance Length ft 82
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
