Technical Information
Service Manual
Model
GWC24MD-D3DNA3F
GWC24MD-D3DNA5F
Product Code
CB171009700
CB162009600
Power
Supply
Rated Voltage V
～
208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min
～
Max) Btu/h 21400(9600~25000)
Heating Capacity(Min
～
Max) Btu/h /
Cooling Power Input(Min
～
Max) W 1780(500~2650)
Heating Power Input(Min
～
Max) W /
Cooling Current Input A 7.9
Heating Current Input A /
Rated Input W 2650
Rated Current A 11.76
Air Flow Volume (S/H/M/L) CFM 500/459/383/324
Dehumidifying Volume Pint/h 5.28
EER (Btu/h)/W 12
COP (Btu/h)/W /
SEER 18
HSPF /
Application Area yd2 32 2/7-50 1/4
Indoor Unit
Indoor Unit Model
GWC24MD-D3DNA3F/I
GWC24MD-D3DNA5F/I
Indoor Unit Product Code
CB171N09700
CB162N09600
Fan Type Cross-ow
Fan Diameter Length(DXL) inch Φ3 6/7X30/1/8
Cooling Speed(S/H/M/L) r/min 1500/1200/1050/900
Heating Speed(S/H/M/L) r/min /
Fan Motor Power Output W 60
Fan Motor RLA A 0.24
Fan Motor Capacitor μF /
Evaporator Form W Aluminum Fin-copper Tube
Evaporator Pipe Diameter inch Φ2/7
Evaporator Row-n Gap inch 2-1/17
Evaporator Coil Length (LXDXW) inch 30 1/8X1X13 1/2
Swing Motor Model MP35XX
Swing Motor Power Output W 3
Fuse Current A 3.15
Sound Pressure Level (S/H/M/L) dB (A) 53/45/41/37
Sound Power Level (S/H/M/L) dB (A) 63/55/51/47
Dimension (WXHXD) inch 39 2/3X12 2/5X8 5/8
Dimension of Carton Box (LXWXH) inch 42 1/4X15 5/9X12 1/3
Dimension of Package (LXWXH) inch 42 1/3X15 2/3X12 21/23
Net Weight lb 29.8
Gross Weight lb 37.5
