Gree GWC24QE-D3DNA1D

8
7HFKQLFDO,QIRUPDWLRQ
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
W
D
H
4 27 7 1/5
5 1/2
7 1/2
1 1/2 1 1/2
Φ2 1/6
Φ2 1/6
3 1/9
6
1 2/3
1 2/3
8 1/9 27 7 1/3
Φ2 3/4
Φ2 3/4
8QLWLQFK
18K
24K
Models W H D
18K 38 1/5 11 4/5 8 5/6
24K 42 4/9 12 4/5 9 2/3
