33
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
Space to the ceiling
Space to the wall
At least 5 8/9 inch
At least 98 3/7 inch
At least 5 8/9 inch
At least 5 8/9 inch
Space to the wall
Space to the obstruction
r
oolfeh
t
o
t
ecapS
Space to the obstruction
Drainage pipe
Space to the wall
Space to the obstruction
Space to the obstructio
Space to the obstruction
At least 19 2/3 inch
At least 11 4/5 inch
At least 19 2/3 inch
At least 11 4/5 inch
At least 78 3/5 inch
At least 118 inch
