22
Technical Information
Service Manual
Indoor unit
Outdoor unit
COOLING
HEATING
4-Way valve
Discharge
Suction
Heat
exchanger
(evaporator)
Heat
exchanger
(condenser)
Valve
Valve
Liquid pipe
side
Gas pipe
side
Accumlator
Compressor
Strainer
StrainerCapillary
4. Refrigerant System Diagram
Connection pipe specication:
Liquid pipe: 1/4"
Gas pipe: 3/8" for 07/09K
1/2" for 12K / 18K / 24K
5/8" for 28K
