Technical Information
Service Manual
Model GWH18ACE-S6DBA1A GWH24ACE-S6DBA1A
Product Code CB497011000/CB497011001 CB497010701
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50/60 50/60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 5300 7034
Heating Capacity W 6200 7034
Cooling Power Input W 1180 1850
Heating Power Input W 1450 1750
Cooling Power Current A 5.9 11
Heating Power Current A 5.9 10.76
Rated Input W 3200 3800
Rated Current A 15 16.4
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 1200/1150/1050/950/850/780/600/500 1200/1050/950/900/850/800/750/550
Dehumidifying Volume L/h 1.8 2
EER W/W 4.49 3.80
COP W/W 4.22 4.00
SEER 6.6 6.5
HSPF / /
SCOP(Awerage/Warmer/Colder) 4.4/5.1/3.4 4.1/5.3/3.5
Application Area m
2
23-34 32-50
Indoor
Unit
Model of indoor unit GWH18ACE-S6DBA1A/I GWH24ACE-S6DBA1A/I
Indoor Unit Product Code CB497N11000/CB497N11001 CB497N10700
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ108X830 Φ106X890
Fan Motor Cooling Speed r/min 1200/1150/1100/1000/900/850/800/600 1250/1100/1000/950/900/850/800/600
Fan Motor Heating Speed r/min 1250/1150/1100/1000/800/700/650 1400/1250/1100/1050/1000/900/850
Output of Fan Motor W 60 70
Fan Motor RLA A 0.24 0.38
Fan Motor Capacitor μF / /
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.4 2-1.5
Coil Length (LXDXW) mm 845X25.4X342.9 845X25.4X381
Swing Motor Model MP24HF MP35CP MP24HF MP35CP
Output of Swing Motor W 1.5 2.5 1.5 2.5
Fuse A 3.15 3.15
Sound Pressure Level
dB
(A)
Cooling:46/44/42/39/36/34/32/28
Heating:47/44/43/40/36/34/32/-
Cooling:50/46/43/41/39/37/35/27
Heating:50/46/43/41/39/37/35/-
Sound Power Level
dB
(A)
Cooling:60/54/52/49/46/44/42/38
Heating:57/54/53/50/46/44/43/-
Cooling:64/60/57/55/53/51/49/41
Heating:64/60/57/55/53/51/49/-
Dimension (WXHXD) mm 1122X329X247 1122X329X247
Dimension of Carton Box (LXWXH) mm 1190X407X335 1190X407X335
Dimension of Package (LXWXH) mm 1193X410X350 1193X410X350
Net Weight kg 16.5 16.5
Gross Weight kg 20 20
