6
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit GWH18ACE-S6DBA1A/O GWH24YE-S6DBA2A/O
Outdoor Unit Product Code CB497W11000 CB466W00301
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXFT-D20zF030 QXFT-D20zF030
Compressor Oil FW68DA FW68DA
Compressor Type Rotary Rotary
L.R.A. A 30 30
Compressor RLA A 10.5 16
Compressor Power Input W 2260 2050
Overload Protector / /
Throttling Method Electron expansion valve Electron expansion valve
Operation Temp
o
C 16~30 16~30
Ambient Temp (Cooling)
o
C -18~52 -18~52
Ambient Temp (Heating)
o
C -30~24 -30~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Ф7 Ф7
Rows-n Gap mm 2-1.4 3-1.5
Coil Length (LXDXW) mm 945X38.1X748 994X57.1X748
Fan Motor Speed rpm 820 820
Output of Fan Motor W 90 90
Fan Motor RLA A 0.65 0.65
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 4000 4000
Fan Type Axial-ow Axial-ow
Fan Diameter mm Ф550 Ф550
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 56/-/- 58/-/-
Sound Power Level (H/M/L) dB (A) 63/-/- 69/-/-
Dimension (WXHXD) mm 1000X790X427 1000X790X427
Dimension of Carton Box (LXWXH) mm 1080X485X840 1080X485X840
Dimension of Package (LXWXH) mm 1083X488X855 1083X488X855
Net Weight kg 61 65
Gross Weight kg 66 70
Refrigerant R32 R32
Refrigerant Charge kg 1.5 2
Connection
Pipe
Length m 5 5
Gas Additional Charge g/m 40 40
Outer Diameter Liquid Pipe 1/4 1/4
Outer Diameter Gas Pipe 5/8 5/8
Max Distance Height m 20 30
Max Distance Length m 50 50
Note: The connection pipe applies metric diameter.
