82
Service Manual
Installation and Maintenance
bRemove the screws fixing evaporator
sub-assy, slightly regulate the tube, to
remove the evaporator sub-assy.
a
motor, to remove the motor.
b
to remove the motor.
9.Remove cross fan blade and motor
auxiliary piping
evaporator sub-assy
up&down swing motor
left&right swing motor
Steps Procedure
To Next Page
