Installation and Maintenance
Service Manual
ProcedureStep
Motor
Cross ow
b
Remove the at the connection place of
cross ow blade and motor; lift the motor
and cross ow blade upwards to remove
them.
8. Remove motor and cross ow blade
Motor clasp
Screws
Remove 3 screws xing motor clamp and
then remove the motor clamp.
a
Clasps
Clasps
Loosen the connection clasps between
vertical louver and bottom case to remove
vertical louver.
9. Remove vertical louver
