Gree GWH12AAB-K3NNA2A

5
Technical Information
Service Manual
Model
1.GWH07AAA-K3NNA1A
2.GWH07AAA-K3NNA2A
3.GWH07AAA-K3NNA3A
4.GWH07AAA-K3NNA4A
1.GWH09AAB-K3NNA1A
2.GWH09AAB-K3NNA2A
3.GWH09AAB-K3NNA3A
4.GWH09AAB-K3NNA4A
Product Code
1.CA115013600/CA115013601
2.CA115014000/CA115014001
3.CA478000301/CA478000300
4.CA479000200
1.CA115013700
2.CA115013900
3.CA478000500
4.CA479001600
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity W 2200 2638
Heating Capacity W 2300 2755
Cooling Power Input W 685 821
Heating Power Input W 637 763
Cooling Power Current A 3.5 4.0
Heating Power Current A 3.2 3.5
Rated Input W 1050 1150
Rated Current A 5.5 5.6
Air Flow Volume(SH/H/M/L/SL) m
3
/h 470/420/370/250/- 570/500/430/300/-
Dehumidifying Volume L/h 0.6 0.8
EER W/W 3.21 3.21
COP W/W 3.61 3.61
SEER W/W / /
HSPF W/W / /
Application Area m
2
10-16 12-18
Indoor Unit
Model of Indoor Unit
1.GWH07AAA-K3NNA1A/I
2.GWH07AAA-K3NNA2A/I
3.GWH07AAA-K3NNA3A/I
4.GWH07AAA-K3NNA4A/I
1.GWH09AAB-K3NNA1A/I
2.GWH09AAB-K3NNA2A/I
3.GWH09AAB-K3NNA3A/I
4.GWH09AAB-K3NNA4A/I
Product Code of Indoor Unit
1.CA115N13600/CA115N13601
2.CA115N14000/CA115N14001
3.CA478N00301/CA478N00300
4.CA479N00200
1.CA115N13700
2.CA115N13900
3.CA478N00500
4.CA479N01600
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ92X505 Φ93X580
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1300/1200/1100/850/- 1300/1200/1100/850/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 1200/1100/1000/900/- 1250/1150/1050/900/-
Output of Fan Motor W 10 20
Fan Motor RLA A 0.15 0.22
Fan Motor Capacitor μF 1 1
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94 Φ7.94
Row-n Gap mm 1-1.2 1-1.2
Coil Length (LXDXW) mm 508X19.05X254 583X19.05X264
Swing Motor Model MP24AN MP24AN
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 40/38/35/27/- 40/37/35/27/-
Sound Power Level (SH/H/M/L/SL) dB (A) 50/48/45/37/- 50/47/45/37/-
Dimension (WXHXD) mm 698X250X185 773X250X185
Dimension of Carton Box (LXWXH) mm 742X306X244 817X306X244
Dimension of Package (LXWXH) mm 747X322X255 822X322X255
Net Weight kg 7.5 8.5
Gross Weight kg 8.5 9.5
