NO. Description
1 Front Panel
2 Filter Sub-Assy
3 Screw Cover
4 Electric Box Cover
5 Rear Grill Sub-assy
6 Front Case
7 Cable Clamp 2
8 Terminal Board
9 Supporter
10 Jumper
11 Main Board
12 Electric Box
13 Display Board
14 Air Louver
15 Helicoid Tongue
16 Plasmacluster Ion
17 Crank
18 Stepping Motor
19 Rear Case
20 Cable Cross Plate
21 Connecting pipe clamp
22 Fan Motor
23 Motor Press Plate
24 Cross Flow Fan
25 Wall Mounting Frame
26 Heat Insulating Hose
27 Evaporator Assy
28 Evaporator Support
29 Remote Controller
30 Temperature Sensor
31 Connecting Cable
32 Connecting Cable
33 O-Gasket sub-assy of Bearing
34 Ring of Bearing
35 Guide Louver
Some models may not contain some parts, please refer to the actual product.
