57
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH07PA-K3NNA6E/I
Product Code CA430N00600 CA430000601
1 Air Louver 1 1051211302 1051211302 1
2 Air Louver 2 1051211402 1051211402 1
3 Helicoid Tongue 2611220202 2611220202 1
4 Left Axile Bush 10512037 10512037 1
5 Rear Case assy 22202254 22202254 1
6 Cross Flow Fan 10352034 10352034 1
7 O-Gasket of Cross Fan Bearing 76512203 76512203 1
8 Ring of Bearing 26152022 26152022 1
9 Evaporator Assy 01002577 01002577 1
10 Wall Mounting Frame 01252231 01252231 1
11 Fan Motor 15012115 15012115 1
12 Motor Press Plate 26112201 26112201 1
13 Drainage Hose 0523001408 0523001408 1
14 Connecting pipe clamp 26112199 26112199 1
15 Rubber Plug (Water Tray) 76712012 76712012 1
16 Stepping Motor 1521212901 1521212901 1
17 Crank 10582070 10582070 1
18 Axile Bush 10542036 10542036 1
19 Guide Louver 1051226802 1051226802 1
20 Terminal Board 42010268 42010268 1
21 Main Board 30135550 30135578 1
22 Front Case 2002224102 2002224102 1
23 Screw Cover 2425201726 2425201726 3
24 Electric Box Cover2 20122168 20122168 1
25 Filter Sub-Assy 11122095 11122095 2
26 Display Board 30565120 30565120 1
27 Front Panel Assy 2002275501 2002275501 1
28 Electric Box Cover 22242112 22242112 1
29 Shield Box (Electric Box) 01592116 01592116 1
30 Electric Box Assy 10000202516 10000202626 1
31 Electric Box 20112091 20112091 1
32 Power Cord 4002046417 4002046417 1
33 Connecting Cable 40020536 40020536 0
34 Connecting Cable 40020540 40020540 0
35 Ambient Temperature Sensor 390000599 390000599 1
36 Temperature Sensor 390000453 390000453 1
37 Remote Controller 30510065 30510468 1
38 Cold Plasma Generator / 1114001602 1
