GWH09PB-K3NNA2E/I
Product Code CA415N01700 CA415N01701
1 Front Panel Assy 20022292 20022292 1
2 Filter Sub-Assy 11122081 11122081 1
3 Screw Cover 24252016 24252016 2
4 Front Case Assy 2002223201 2002223201 3
5 Air Louver 1 1051211302 1051211302 1
6 Air Louver 2 1051211402 1051211402 1
7 Helicoid Tongue 2611216202 2611216202 1
8 Rear Case assy 22202186 22202186 1
9 Rubber Plug (Water Tray) 76712012 76712012 1
10 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
11 O-Gasket of Cross Fan Bearing 76512203 76512203 1
12 Cross Flow Fan 10352018 10352018 1
13 Evaporator Support 24212090 24212090 1
14 Evaporator Assy 01002000037 01002000037 1
15 Wall Mounting Frame 01252015 01252015 1
16 Motor Press Plate 26112160 26112160 1
17 Fan Motor 15012115 15012115 1
18 Pipe Clamp 2611216401 2611216401 1
19 Drainage Hose 0523001406 0523001406 1
20 Step Motor 1521212901 1521212901 1
21 Crank 10582070 10582070 1
22 Guide Louver 10512204 10512204 1
23 Axile Bush 10542036 10542036 1
24 Electric Box 2011216701 2011216701 1
25 Terminal Board 42010268 42010268 1
26 Electric Box Cover2 20122075 20122075 1
27 Main Board 30135550 30135578 1
28 Jumper 4202300123 4202300123 1
29 Display Board 30565211 30565211 1
30
Shield Cover of Electric Box
Sub-assy
0159207301 0159207301 1
31 Electric Box Cover1 22242135 22242135 1
32 Electric Box Assy 10000202504 10000202630 1
33 Power Cord 4002046417 4002046417 1
34 Connecting Cable 40020536 40020536 0
35 Connecting Cable 40020540 40020540 0
36 Ambient Temperature Sensor 390000599 390000599 1
37 Temperature Sensor 390000453 390000453 1
38 Remote Controller 30510065 30510468 1
39 Cold Plasma Generator / 1114001602 1
To Next Page
