78
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH12PC-K3NNA9E/I
Product Code CA429N00900 CA415N01801
1 Front Panel Assy 2002274401 2002274401 1
2 Display Board 30565275 30565275 1
3 Filter Sub-Assy 1112220403 1112220403 2
4 Screw Cover 2425201726 2425201726 3
5 Front Case Sub-assy 2002236101 2002236101 1
6 Air Louver 1 1051215603 1051215603 1
7 Air Louver 2 1051215503 1051215503 1
8 Helicoid Tongue 2611216302 2611216302 1
9 Left Axile Bush 10512037 10512037 1
10 Rear Case assy 22202467 22202467 1
11 Rubber Plug (Water Tray) 76712012 76712012 1
12 Ring of Bearing 26152022 26152022 1
13 O-Gasket of Cross Fan Bearing 76512203 76512203 1
14 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
15 Cross Flow Fan 10352017 10352017 1
16 Evaporator Support 24212091 24212091 1
17 Evaporator Assy 01002565 01002565 1
18 Wall Mounting Frame 01252021 01252021 1
19 Motor Press Plate 26112161 26112161 1
20 Fan Motor 150120874 150120874 1
21 Pipe Clamp 2611216401 2611216401 1
22 Drainage Hose 0523001401 0523001401 1
23 Step Motor 1521212901 1521212901 1
24 Crank 10582070 10582070 1
25 Guide Louver 1051220303 1051220303 1
26 Axile Bush 10542036 10542036 1
27 Electric Box 2011216701 2011216701 1
28 Terminal Board 42010268 42010268 1
29 Electric Box Cover2 2012207512 2012207512 1
30 Main Board 30135550 30135578 1
31 Shield Cover of Electric Box Sub-assy 0159207301 0159207301 1
32 Electric Box Cover1 22242135 22242135 1
33 Electric Box Assy 10000202535 10000200789 1
34 Power Cord 4002046417 4002046417 1
35 Connecting Cable 40020536 40020536 0
36 Connecting Cable 40020540 40020540 0
37 Ambient Temperature Sensor 390000599 390000599 1
38 Remote Controller 30510065 30510468 1
39 Temperature Sensor 390000453 390000453 1
40 Cold Plasma Generator / 1114001602 1
To Next Page
