Technical Information
Service Manual
Model
1.GWH24QE-S6DBD2A 2.GWH24QE-S6DBE4A
3.GWH24QE-S6DBE6A 4.GWH24QE-S6DBD6A
Product Code
1.CB461006000 2.CB470005300
3.CB465003500 4.CB460007100
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50/60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 7034
Heating Capacity W 7034
Cooling Power Input W 1850
Heating Power Input W 1750
Cooling Power Current A 11
Heating Power Current A 10.76
Rated Input W 3800
Rated Current A 16.4
Rated Heating Current A 16.4
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 1200/1050/950/900/850/750/700
Dehumidifying Volume L/h 2
EER W/W 3.8
COP W/W 4
SEER W/W 6.5
HSPF W/W /
SCOP(Average/Warmer/Colder) 4.1/5.3/3.5
Application Area m
2
32-50
Indoor Unit
Model of indoor unit
1.GWH24QE-S6DBD2A/I 2.GWH24QE-S6DBE4A/I
3.GWH24QE-S6DBE6A/I 4.GWH24QE-S6DBD6A/I
Indoor Unit Product Code
1.CB461N06000 2.CB470N05300
3.CB465N03500 4.CB460N07100
Fan Type Cross-ow
Diameter Length(DXL) mm Φ106X890
Fan Motor Cooling Speed r/min 1250/1100/1000/950/900/850/800/600
Fan Motor Heating Speed r/min 1400/1250/1100/1050/1000/900/850
Output of Fan Motor W 60
Fan Motor RLA A 0.24
Fan Motor Capacitor μF /
Input of Heater W /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2-1.5
Coil Length (LXDXW) mm 845X25.4X381
Swing Motor Model MP35CJ/MP24HF
Output of Swing Motor W 2.5/1.5
Fuse A 3.15
Sound Pressure Level (SH/H/MH/M/ML/L/SL) dB (A) 50/46/43/41/39/37/35
Sound Power Level (SH/H/MH/M/ML/L/SL) dB (A) 64/60/57/55/53/51/49
Dimension (WXHXD) mm 1078X325X246
Dimension of Carton Box (LXWXH) mm 1145X410X335
Dimension of Package (LXWXH) mm 1148X413X350
Net Weight kg 16.5
Gross Weight kg 20
