Gree JKFD15QSR/Na-M

GREE Air-ccoled Closed Control Unit Service Manual
121
13
Detecting Plate 30270005
1
14
Discharge Tube Sub-assy 030013000146
1
15
Square Valve 07138800
1
16
Drainage Pipe Sub-assy 1 030065000007
1
17
Compressor Gasket 76812203
1
18
Package Base 50233733
1
19
Electrical Heater(Compressor) 7651521237
1
20
Compressor and Fittings 00203720
1
21
Gas-liquid Separator 07424146
1
22
Terminal Board 42010052
1
23
Water Immersion Switch 45020501
1
24
Square Valve 07130366
1
25
Strainer 07213051
1
26
Electric Expansion Valve Sub-Assy 030026000057
1
27
Electronic Expansion Valve 43042800069
1
28
Electric Expand Valve Fitting 4304413228
1
29
Drainage Pipe Sub-assy 04263700083
1
30
Connection pipe sub-assy 030062000132
1
31
Humidifier Assy 000156000002
1
32
Connection pipe sub-assy 030062000133
1
33
Evaporator Assy 011001000068
1
34
Rubber cushion 76018401
1
35
Motor for Centrifugal Fan 15403719
1
36
Fan Motor 1570371101
1
37
Electric Heater 32105200001
1
38
Temperature Limiter 46010514
1
39
Pressure Difference Switch 46028251
1
（Refer to actual products for unit structure and materials. ）
◆ Parts list of model JKFD5CR/Na-E(I)
Compared with model JKFD5QSR/Na-E(I)
，it just adds false ogive. So please refer to parts
list of model JKFD5QSR/Na-E(I).
（2）Indoor Unit JKFD7CR/Na-M(I)、JKFD7QSR/Na-M(I)
◆
Exploded view of JKFD7QSR/Na-M(I)（applicable to JKFD7CR/Na-M(I)）
