GREE Air-ccoled Closed Control Unit Service Manual
15
Indoor Unit
Indoor Unit Model
JKFD40C/Na-M(I)
JKFD40QS/Na-M(I)
Dimension
W
mm
2480
2480
D
mm
810
810
H
mm
2250
1950
Net Weight
kg
755
690
Outdoor Unit
Outdoor Unit Model
JKFD40/Na-M(O)
Qty
Set
1
Condensing
Fan
Type
Low Noise Axial Type
Type of Drive
Direct Drive
Noise
dB(A)
64
Dimension
W
mm
2500
D
mm
1150
H
mm
1250
Net Weight
kg
240
Connection pipe
Liquid
Refrigerant
Pipe
mm×pcs
Φ19×1
Gas
Refrigerant
Pipe
mm×pcs
Φ22×1
Method of Connection
Welding
Notes:
1. This unit was designed, manufactured and tested according to National Standard GB/T
19413-2010.
2. Ambient temperature when testing cooling capacity：dry-bulb temperature indoors is
24℃ and wet-bulb temperature is 17℃; dry-bulb temperature of outdoor side: 35℃.
3. The noise value was tested in the semi-anechoic chamber but the actual value will be a
little higher for the change of ambient temperature.
4. Refer to nameplate on the unit for parameters of the unit. And the unit is Subject to
change without further notice.
5. The temperature range of running environment is between：-35℃～48℃。
6. All models above can realize modular operation.
7. If there is any special requirement, please contact us.
5. Rformance correctlon
5.1 Correction of Cooling Capacity
Under different indoor or outdoor ambient temperatures, the cooling capacity of the unit will
be different. The below diagram can be reference when customer select models.
