Gree JKFD5DQS/Na-E - Installation of the Unit; Installation Diagram of the Complete Unit; Outline Dimension of the Unit

GREE Air-ccoled Closed Control Unit Service Manual
19
6. Installation of the unit
6.1 Installation Diagram of the Complete Unit
The complete unit consists of outdoor unit and indoor unit, which is shown as below:
6.2 Outline Dimension of the Unit
6.2.1 Indoor Unit
◆Outline Dimension of JKFD5 and JKFD7 Series (Direct Air Supply)
Right Side
Front Side
Back Side
(The picture is for a reference only and the actual item is the standard. Unit: mm)
◆ Outline Dimension of Indoor units of JKFD5 and JKFD7 Series (Top Air Outlet)
