GREE Air-ccoled Closed Control Unit Service Manual
18
the relative equivalent length of elbow and oil loop
Outside Diameter of
Connecting Pipe(mm)
Elbow (m)
Oil Loop (m)
Ф9.52
0.2
1.4
Ф12
0.25
1.8
Ф16
0.3
2
Ф19
0.35
2.4
Ф22
0.4
2.8
Note: The equivalent pipe length equals the length of straight pipe plus the equivalent length of
elbow and oil loop.
