GREE Air-ccoled Closed Control Unit Service Manual
134
38 Column (fixing beam) 01853739P 1
39 Discharge pipe1 04633730 1
40 Level glass sub-assy 1 22453701 1
41 Air-return pipe1 04673738 1
42 Level glass sub-assy 2 22453702 1
43 Installation beam of compressor 01873787P 2
44 Cut-off valve 2 07333750 2
45 Cut-off valve 2 07333751 2
46 Column sub-assy (right front) 01853742P 1
47 Fixing bea 2 01873785P 1
48 Base 01283759 1
49 Strainer 2 07413710 1
50 Strainer 1 07413709 1
51 Fixing bea 1 01873784P 1
52 Water tray(base) 01283763P 1
53 Nozzle sub-assy 05023742 1
54 Guard board (electric heater) 01353738P 2
55 Water tray 01283764P 2
56 Packing base(wood) 50233727 1
57 Mounting beam (electric heater) 01323756P 4
58 Column (lower) 01853777P 4
59 Electric cabinet 01393751P
（8）Outdoor Unit JKFD5P/Na-E(O)、JKFD7P/Na-E(O)
◆
Exploded view of JKFD5P/Na-E(O)（applicable to JKFD7P/Na-E(O)）
