Gree JKFD7CR/Na-M

GREE Air-ccoled Closed Control Unit Service Manual
123
17
Compressor Gasket 76812203
1
18
Package Base 50233733
1
19
Electrical Heater(Compressor) 7651521237
1
20
Compressor and Fittings 00203711
1
21
Gas-liquid Separator 07424146
1
22
Terminal Board 42010052
1
23
Water Immersion Switch 45020501
1
24
Square Valve 07130366
1
25
Strainer 07213051
1
26
Electric Expansion Valve Sub-Assy 030026000057
1
27
Electronic Expansion Valve 43042800069
1
28
Electric Expand Valve Fitting 4304413228
1
29
Drainage Pipe Sub-assy 04263700083
1
30
Connection pipe sub-assy 030062000132
1
31
Humidifier Assy 000156000002
1
32
Connection pipe sub-assy 030062000133
1
33
Evaporator Assy 011001000068
1
34
Centrifugal Fan sub-assy 15403718
1
35
Rubber cushion 76018401
1
36
Electric Heater 32105200001
1
37
Temperature Limiter 46010514
1
38
Pressure Difference Switch 46028251
1
◆ Parts' list of JKFD7CR/Na-M(I)
Compared with model JKFD7QSR/Na-M(I)
，it just doesn’t have false ogive. So please refer to
parts list of model JKFD7QSR/Na-M(I).
（3）Indoor Unit JKFD15CR/Na-M(I)、JKFD15QSR/Na-M(I)、JKFD20CR/Na-M(I)、
JKFD20QSR/Na-M(I)
◆
Exploded view of JKFD15QSR/Na-M(I)（applicable to JKFD15CR/Na-M(I)、
JKFD20CR/Na-M(I)、JKFD20QSR/Na-M(I)）
