GREE Air-ccoled Closed Control Unit Service Manual
137
RGE-Z1Q4-7
11 Fan 15403714 1
12 Rear side plate 01313732P 1
13 Rear cover plate 01263730P 1
14 Connecting part 01343747 4
◆ Parts' list of JKFD19/NaA-M(O)
No. Part Name Material Code Q’ty
1 Side plate sub-assy 01313735P 2
2 Support leg 01893728P 4
3 Support stand 01803767P 4
4 Condenser 01123718 1
5 Front side plate sub-assy 01313733P 1
6 Cut-off part 07333814 1
7 Cut-off part 07333815 1
8 Front cover plate 01263731P 1
9 Electric box JKFD13(O) 01393748 1
10
Speed controller of fan
RGE-Z1Q4-7
30118025 1
11 Axial flow fanC-FZ630J 15403715 1
12 Rear side plate 01313732P 1
13 Rear cover plate 01263730P 1
14 Connecting part 01343747 4
（12）Outdoor Unit JKFD15P/Na-M(O)、JKFD20P/Na-M(O)
◆
Exploded view of JKFD15P/Na-M(O)（applicable to JKFD20P/Na-M(O)）
