Receiver JS13
9
3.2 Installation Method
(1) When the indoor unit is installed well, select an installation position for the
remote signal receiver according to the size of the connection wire and
the installation position of the unit, leaving a groove and buried wire slot
to install the remote signal receiver and bury the connection wires;
(2) Drill holes on the installation wall according to the installation dimension
in the middle of the receiver dimension drawing, and then insert expanded
plastic into each hole;
(3) Bury the connection wire and fix the connection wire with the screw at the
back of the receiver body;
(4) If Junction box is reserved, please fix the receiver body in the Junction
box with screw M4×25. If Junction box is not reserved, please fix the
receiver body directly on the installation position with tapping screw
ST3.5×25 PA and then assemble the cover;
(5) Connect the connection wire to the corresponding position of the unit
where connecting the wired controller to complete the installation.
