Service Manual
3. Malfunction of Protection of Jumper Cap C5
Main detection points:
● Is there jumper cap on the mainboard?
● Is the jumper cap inserted correctly and tightly?
● The jumper is broken?
● The motor is broken?
● Detection circuit of the mainboard is dened abnormal?
Malfunction diagnosis process:
Start
Is there jumper cap on the mainboard?
Is the jumper cap inserted correctly
and tightly?
Replace the jumper cap with
the same model
Appearance of the
jumper cap
Assemble the jumper
cap with the same model
Insert the jumper
cap tightly
Is malfunction
eliminated
Is malfunction
eliminated
Is malfunction
eliminated
Replace the mainboard
with the same model
End
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
64

Gree LIVV12HP230V1AH Specifications

General

Model	LIVV12HP230V1AH
Energy Efficiency Ratio (EER)	12.0
Refrigerant	R410A
Indoor Unit Noise Level	42 dB(A)
Type	Split System Air Conditioner
Cooling Capacity	12, 000 BTU/h
Heating Capacity	12000 BTU/h
Power Supply	230V / 60Hz / 1Ph
Weight (Indoor Unit)	22 lbs
Outdoor Unit Noise Level	54 dB(A)
