Gree LIVV24HP230V1A Series

40
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
W
D
H
3 1/2
6
2 1/8
2 1/8
6 5/8 18 3/16 6 5/16
Φ2 3/16
Φ2 3/16
Φ2 3/16
Φ2 3/16
4 11/16 21 5/1
67
1/4
3 5/16
5
1 3/8
1 3/8
427 7 3/16
5 1/2
7 1/2
1 1/2
Φ2 3/16
Φ2 3/16
3 1/8
6
1 11/16
8 1/8 27 7 5/16
Φ2 3/4
Φ2 3/4
MODEL W H D
LIVV09 31 1/8 10 3/4 7 7/8
LIVV12 33 1/4 11 1/4 8 3/8
LIVV18 38 1/4 11 3/4 8 3/4
LIVV24 42 1/4 12 3/4 9 5/8
Unit:inch
LIVV09HP230V1AH LIVV12HP230V1AH
LIVV18HP230V1AH LIVV24HP230V1AH
10
