Gree LIVV24HP230V1A Series

28
Service Manual
Model
LIVV24HP230V1A
Product Code CB432021500
Power Supply
Rated Voltage V~
208/230
Rated Frequency Hz
60
Phases
1
Power Supply Mode
Outdoor
Cooling Capacity(Min~Max) Btu/h
22000
Heating Capacity(Min~Max) Btu/h
24000
Cooling Power Input(Min~Max) W
1950
Heating Power Input(Min~Max) W
2070
Cooling Power Current A
8.50
Heating Power Current A
8.50
Rated Input W
2900
Rated Current A
11.00
Air Flow Volume(SH/H/M/L) CFM
677/588/471/412
Dehumidifying Volume Pint/h
2
EER (Btu/h)/W
11.25
COP (Btu/h)/W
11.75
SEER
19.00
HSPF
10
Application Area yd
2
27.50-40.66
Indoor Unit
Model of indoor unit
LIVV24HP230V1AH
Indoor Unit Product Code
CB432N21500
Fan Type
Cross-ow
Diameter Length(DXL) inch
Φ4 1/4X32 43/64
Fan Motor Cooling Speed(SH/H/M/L) r/min
1300/1150/1000/850
Fan Motor Heating Speed(SH/H/M/L) r/min
1300/1150/1000/850
Output of Fan Motor W
30
Fan Motor RLA A
0.55
Fan Motor Capacitor μF
3
Evaporator Form
Aluminum Fin-copper Tube
Pipe Diameter inch
Φ17/64
Row-n Gap inch
2-1/16
Coil Length (LXDXW) inch
33 1/4×1×13 1/2
Swing Motor Model
MP35CJ
Output of Swing Motor W
2.5
Fuse A
3.15
Sound Pressure Level(SH/H//M/L) dB (A)
49/45/41/37
Sound Power Level(SH/H//M/L) dB (A)
59/55/51/47
Dimension (WXHXD) inch
42 7/16X12 13/16X9 11/16
Dimension of Carton Box (LXWXH) inch
45X16 1/8X13 3/16
Dimension of Package (LXWXH) inch
45 3/16X16 1/4X13 3/4
Net Weight Ib
37.5
Gross Weight Ib
45.2
