Gree PULAR Series

11
Technical Information
Service Manual
Model GWH24AGD-K6DNA1C GWH24AGD-K6DNA1C
Product Code
CB385008600
CB385008601
CB385008602
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 6200 6200
Heating Capacity W 6500 6500
Cooling Power Input W 1786 1786
Heating Power Input W 1645 1645
Cooling Power Current A 7.6 7.6
Heating Power Current A 7.6 7.6
Rated Input W 2200 2200
Rated Current A 9.3 9.3
Rated Heating Current A 9.7 9.7
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h
1050/950/800/750/700/650/600
950/800/700/650/600/540/500
Dehumidifying Volume L/h 2 2
EER W/W 3.47 3.47
COP W/W 3.95 3.95
SEER W/W 6.8 6.8
SCOP(Average/Warmer/Colder) 4/5.1/- 4/5.1/-
HSPF / /
Application Area m
2
23-34 23-34
Indoor Unit
Indoor Unit Model GWH24AGD-K6DNA1C/I GWH24AGD-K6DNA1C/I
Indoor Unit Product Code
CB385N08600
CB385N08601
CB385N08602
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ106X739 Φ106X739
Fan Motor Cooling Speed(SS/H/MH/M/ML/
L/SL)
r/min 1350/1200/1100/1000/900/850/800 1350/1200/1100/1000/900/850/800
Fan Motor Heating Speed(SS/H/MH/M/ML/
L/SL)
r/min 1350/1200/1100/1000/900/850/800 1350/1200/1100/1000/900/850/800
Output of Fan Motor W 50 50
Fan Motor RLA A 0.24 0.24
Fan Motor Capacitor μF 3 3
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 745X22.8X342.9 745X22.8X342.9
Swing Motor Model MP24BA/MP24AK/MP24HF MP24BA/MP24AK
Output of Swing Motor W 1.5/1.5/1.5 1.5/1.5
Fuse A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/ML/L/
SL)
dB (A)
Cooling:46/44/40/37/35/32/30
Heating:48/44/40/37/34/32/30
Cooling:46/42/40/37/35/32/30
Heating:48/44/40/37/34/32/30
Sound Power Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:63/59/57/54/53/49/47
Heating:63/59/55/52/49/47/45
Cooling:63/59/57/54/53/49/47
Heating:63/59/55/52/49/47/45
Dimension (WXHXD) mm 982X311X221 982X311X221
Dimension of Carton Box (LXWXH) mm 1039X377X287 1039X377X287
Dimension of Package (LXWXH) mm 1044X385X297 1044X385X297
Net Weight kg 14 14
Gross Weight kg 16.5 16.5
