12
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH24AGD-K6DNA1C/O
Product Code of Outdoor Unit CB385W08600
Compressor Manufacturer/Trademark ZHUHAI LINDA COMPRESSOR CO., LTD
Compressor Model FTz-SM151AXBD
Compressor Oil FW68DA
Compressor Type Rotary
L.R.A. A /
Compressor RLA A 6.06
Compressor Power Input W 1330
Overload Protector /
Throttling Method Capillary
Operation Temp
o
C 16~30
Ambient Temp (Cooling)
o
C -15~43
Ambient Temp (Heating)
o
C -15~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94
Rows-n Gap mm 2-1.4
Coil Length (LXDXW) mm 848X38.1X528
Fan Motor Speed rpm 900
Output of Fan Motor W 40
Fan Motor RLA A 0.70
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit m
3
/h 2800
Fan Type Axial-ow
Fan Diameter mm Φ445
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 57/-/-
Sound Power Level (H/M/L) dB (A) 65/-/-
Dimension (WXHXD) mm 873X555X376
Dimension of Carton Box (LXWXH) mm 948X428X591
Dimension of Package (LXWXH) mm 951X431X620
Net Weight kg 36.5
Gross Weight kg 39.5
Refrigerant R32
Refrigerant Charge kg 1.18
Connection
Pipe
Length m 5
Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 1/2
Max Distance Height m 10
Max Distance Length m 25
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
