Service Manual
Technical Information
7
Indoor side
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ205X109.5 Φ197.6X111
Input of Heater W 190 100
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 3-1.3 3-1.3
Coil Length (LXHXW) mm 401X38.1X381 401X38.1X381
Swing Motor Model SM020B SM020B
Output of Swing Motor W 4 4
Fuse A / /
Sound Pressure Level (H/M/L) dB (A) 55/53/51 50/48/46
Sound Power Level (H/M/L) dB (A) 65/63/61 60/58/56
Outdoor
side
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-D184F090AA QXF-B133E090
Compressor Oil FW68DA FW68DA
Compressor Type Rotary Rotary
L.R.A. A 41 27.5
Compressor RLA A 5.84 4.4
Compressor Power Input W 1320 955
Overload Protector UP3-B7 HPA-325
Throttling Method Capillary Capillary
Operation Temp ºC 16~30 16~30
Ambient temp (Cooling) ºC 18~43 18~43
Ambient temp (Heating) ºC / /
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Rows-n Gap mm 3-1.3 2-1.3
Coil Length (LXHXW) mm 839X34.2X400.05 688X22.8X400.05
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ396 Φ391
Sound Pressure Level (H/M/L) dB (A) 63/60/57 60/58/56
Sound Power Level (H/M/L) dB (A) 72/69/66 70/68/66
Defrosting Method / /
Model
GJC21AE-K6NRNR1A
GJC21AE-K6NRNR1B
GJC21AE-K6NRNB3A
GJC21AE-K6NRNG1A
GJH12AG-K6NRNR1A
GJH12AG-K6NRNR1B
GJH12AG-K6NRNB3A
GJH12AG-K6NRNB9A
Product code
CC053008100
CC053016200
CC053025800
CC053030000
CC053010700
CC053016300
CC053026000
CC053027900
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity W 6000 3900
Heating Capacity W / 3600
Cooling Power Input W 1810 1180
Heating Power Input W / 1060
Cooling Power Current A 7.87 5.13
Heating Power Current A / 4.53
Rated Input W 2400 1600
Rated Current A 12.8 7.5
Air Flow Volume(H/M/L) m
3
/h 860/800/740 660/610/560
Dehumidifying Volume L/h 2.2 1.5
EER W/W 3.31 3.31
COP W/W / 3.4
SEER W/W / /
HSPF W/W / /
Application Area m
2
27-42 16-24
Fan Motor Speed(H/M/L) rpm 1060/980/900 900/830/760
Output of Fan Motor W 190 100
Fan Motor RLA A 1.6 0.73
Fan Motor Capacitor μF 7 4
Climate Type T1 T1
Isolation I I
Moisture Protection(Outdoor) IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 2.5 2.5
Dimension (WXHXD) mm 660X428X770 660X428X700
Dimension of Carton Box (LXWXH) mm 860X736X490 790X736X490
Dimension of Package (LXWXH) mm 863X739X505 793X739X505
Net Weight kg 61 51
Gross Weight kg 65 55
Refrigerant R32 R32
Refrigerant Charge kg 0.78 0.86
