Service Manual
Technical Information
8
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Indoor side
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ227X109.8 Φ197.6X111
Input of Heater W 190 100
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 4-1.5 4-1.6
Coil Length (LXHXW) mm 400X50.8X381 400X50.8X381
Swing Motor Model SM020B SM020B
Output of Swing Motor W 4 4
Fuse A / /
Sound Pressure Level (H/M/L) dB (A) 55/53/51 50/48/46
Sound Power Level (H/M/L) dB (A) 65/63/61 60/58/56
Outdoor
side
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-E21H090 QXF-B133E090
Compressor Oil FW68DA FW68DA
Compressor Type Rotary Rotary
L.R.A. A 39.00 27.5
Compressor RLA A 6.70 4.4
Compressor Power Input W 1520 955
Overload Protector HPA-340 HPA-325
Throttling Method Capillary Capillary
Operation Temp ºC 16~30 16~30
Ambient temp (Cooling) ºC 18~43 18~43
Ambient temp (Heating) ºC / -7~30
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ7
Rows-n Gap mm 3-1.3 2-1.3
Coil Length (LXHXW) mm 839X34.2X400.05 685X25.4X400
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ396 Φ391
Sound Pressure Level (H/M/L) dB (A) 62/59/56 60/58/56
Sound Power Level (H/M/L) dB (A) 72/69/66 70/68/66
Defrosting Method / /
