Service Manual
Technical Information
26
07/09K
●Top view
●Bottom view
No Name No Name No Name
1 Indoor Ambient Temp Sensor 6 Four-way Value Contector 11 Fuse
2 Indoor Ambient/Indoor Tube Temp Sensor 7 Resistance-capacitance Module 12 Compressor Relay
3 Outdoor Tube Temp Sensor 8 Fan Speed Interface 13 Resistance-capacitance Module
4 Swing Interface Needle Stand 9 Voltage Dependent Resistor 14 Shingle Wire Interface Needle Stand
5 WIFI Moudle Interface Neddle Stand 10 Copeer Insert Of Neutral Wire
1 2 3 4 5 6 7
8
9
10
11121314
To Next Page
