Gree R1 - 5.2.2 Silk screen on display board

Service Manual
Technical Information
27
●Top view
●Bottom view
678910111213141516
18 19 20 21 12 34 517
NO. NameNO. Name NO.NameNO. Name
1
Connecting wire between
boards to mainboard
7 Mode button13LED lamp of med. Fan speed19Filter cleaning button
2 “-” button8LED lamp of cooling14Swing button20Filter cleaning LED lamp
3LED lamp of timer 9ON/OFF button15LED lamp of high speed21 “+”button
4Timer button10LED lamp of drying 16 Fan speed button22/
5LED lamp of heating11Nixie tube 17 LED lamp of low fan speed23/
6LED lamp of fan12Infrared receiver 18 Auto mode 24 /
5.2.2 Silk screen on display board
