OUTDOOR UNIT INSTALLATION
Condensate Drainage of the Outdoor Unit
The outdoor unit should be installed with a drain pipe to drain condensate water during the heating mode.
1. Insert the drain joint (included) into the selected hole located on the bottom of the base pan
and then connect the drain hose (field supplied) to the drain joint.
2. All other holes must be sealed with plugs (included) to avoid water leaks, except for the drain
pipe mounting hole.
3. Route drain hose to safe location for disposing of condensate water.
The unit should be located with the unit support feet firmly on the equipment pad.
If the outdoor unit is exposed to wind, it must be properly secured.
WARNING
Model ABCDE
UMAT18HP230V1AO
37-5/8 15-5/8 27-1/2 22 14-1/8
(955) (396) (700) (560) (360)
UMAT24HP230V1AO 38-5/8 16-3/4 31-1/8 24 15-1/2
UMAT30HP230V1AO (980) (427) (790) (610) (395)
UMAT36HP230V1AO 43-5/8 17-3/8 43-1/4 24-7/8 15-3/4
UMAT42HP230V1AO (1107) (440) (1100) (631) (400)
UMAT48HP230V1AO
37-3/4 16-1/4 53-1/8 22-1/2 14-3/4
(958) (412) (1349) (572) (376)
OUTDOOR UNIT DIMENSIONS in (mm)
13
