STANDARD PARTS
Indoor Unit Accessories
Outdoor Unit Accessories
No. Name Appearance Qty Usage
1 Drain Hose 1 Connects with field
supplied drain pipe
2 Screw with Washer 4 Secures the hook on the
cabinet of the unit
3 Washer 10 Used together with the hanger
bolt for installing the unit
4 Installation Template 1 Used for ceiling drilling
5 Gasket Mounting Board 4 Prevents gasket from
falling off
6 Remote Controller 1 Remotely controls the
indoor unit
7 Cable Clamp 4 Fastens the insulation to pipe
8 Pipe Insulation 1 Insulates the gas pipe
9 Pipe Insulation 1 Insulates the liquid pipe
10 Insulation 4
Insulates the drain pipe
11 Flare Nut 1 Connects the gas pipe
12 Flare Nut 1 Connects the liquid pipe
13 Service Valve Cap 2 Protects service port
7
No. Name Appearance Qty Usage
1 Drain Plug 2 or 3 Plugs the unused drain hole
2 Drainage Connecter
or
1
Connects with the hard
PVC drain pipe
