Greenheck BSQ User Manual

472058 • SQ BSQ, Rev. 6, January 2019 Copyright 2019 © Greenheck Fan Corporation12
As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications
without notice.
Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature
section of the website at Greenheck.com/Resources/Library/Literature.
®
Phone: 715.359.6171 • Fax: 715.355.2399 • Parts: 800.355.5354 • E-mail: gfcinfo@greenheck.com • Website: www.greenheck.com
Our Commitment
AMCA Publication 410-96, Safety Practices for Users and
Installers of Industrial and Commercial Fans, provides
additional safety information. This publication can be obtained
from AMCA International, Inc. at www.amca.org.
Greenheck’s Centrifugal Inline Fans catalog provides
additional information describing the equipment, fan
performance, available accessories, and specification data.
Direct Drive Centrifugal
Inline Exhaust Fan
Belt Drive Centrifugal
Inline Exhaust Fan
Parts List
Each fan bears a manufacturer’s nameplate with model number and serial number embossed. This information will
assist the local Greenheck representative and the factory in providing service and replacement parts. Before taking
any corrective action, make certain unit is not capable of operation during repairs.
ATTENTION
La présence d’un moteur antidéflagrant sur un
ventilateur ne garantit pas que tout l’appareil est
antidéflagrant. Pour connaître les emplois autorisés
de l’appareil, voir son marquage de conformité UL.
CAUTION
A fan manufactured with an explosion resistant
motor does not certify the entire unit to be explosion
resistant. Refer to ULListing Mark for the fans
approved usage.
VENTURI
WHEEL
SHAFT BEARINGS BEARING
COVER
BELT
BELT
TUBE
SHAFT
PULLEY
HOUSING
BEARING
SUPPORT
MOTOR
MOTOR
PULLEY
VENTURI PANEL
ACCESS
DOOR
WHEEL
BELT
TUBE
BEARING
COVER
ACCESS
DOOR
MOTOR
SUPPORT
ANGLES
MOTOR
PLATE
MOTOR
MOTOR
PULLEY
BELT
VENTURI
WHEEL
ACCESS
PANEL
HOUSING
VENTURI
PANEL
WHEEL
MOTOR
COVER
MOTOR
MOTOR
COVER
MOTOR
ACCESS
PANEL
