Greenheck BSQ User Manual

Centrifugal Inline Fans6
®
Direct Drive Side Discharge Duct Openings
Size Width Height
60, 70 9
7
⁄8 (251) 8
7
⁄8 (225)
80, 90, 95 12
7
⁄8 (327) 11
7
⁄8 (302)
97, 98, 99 13
7
⁄8 (352) 11
7
⁄8 (302)
100 13
7
⁄8 (352) 13
7
⁄8 (352)
120 15
7
⁄8 (403) 15
7
⁄8 (403)
130 (HP) 17
7
⁄8 (454) 17
7
⁄8 (454)
140 (HP) 19
7
⁄8 (505) 19
7
⁄8 (505)
160 (HP) 22
7
⁄8 (581) 22
7
⁄8 (581)
Belt Drive Side Discharge Duct Openings
70, 80, 90, 100 12
1
⁄2 (317) 13
7
⁄8 (352)
120 12
1
⁄2 (317) 15
7
⁄8 (403)
130 (HP) 12
1
⁄2 (317) 17
7
⁄8 (454)
140 (HP) 13
1
⁄2 (342) 19
7
⁄8 (505)
160 (HP) 17
1
⁄2 (444) 22
7
⁄8 (581)
180 (HP) 19
1
⁄2 (494) 23
7
⁄8 (606)
200 (HP) 23
1
⁄2 (596) 27
7
⁄8 (708)
240 (HP) 25
1
⁄2 (647) 34
7
⁄8 (886)
300 (HP) 31
7
⁄8 (810) 41
7
⁄8 (1064)
360 (HP) 32
7
⁄8 (835) 37
7
⁄8 (962)
420 34
7
⁄8 (886) 43
7
⁄8 (1114)
All dimensions in inches (millimeters).
Figure 8
Height
Left Side
Discharge
Right Side
Discharge
Inline
Discharge
Inlet
Width
Side Discharge
Make sure discharge is oriented in the same direction
as originally ordered, performance will change with
different discharge positions. Refer to Figure 8 for
proper side discharge definition and the Side Discharge
chart for dimensions. Consult factory for performance
corrections.
Duct Length
The inlet and outlet duct length should be approximately
two to three wheel diameters long before and after the
fan to achieve cataloged performance.
Direct Drive Isolator Dimensional Data
Size H I J J1 K L
60, 70
1
3
⁄8
(35)
5
1
⁄2
(140)
1
3
⁄8
(35)
2
3
⁄8
(60)
6
3
⁄4
(171)
2
5
⁄16
(59)
80, 90, 95
97, 98, 99
100
120
130 (HP)
140 (HP)
160 (HP)
1
3
⁄8
(35)
5
1
⁄2
(140)
1
3
⁄8
(35)
2
1
⁄2
(64)
6
3
⁄4
(171)
2
5
⁄8
(67)
Belt Drive Isolator Dimensional Data
70, 80, 90
1
3
⁄8
(35)
5
1
⁄2
(140)
1
3
⁄8
(35)
2
3
⁄8
(60)
6
3
⁄4
(171)
2
5
⁄8
(67)
100
120
130 (HP)
140 (HP)
160 (HP)
1
3
⁄8
(35)
5
1
⁄2
(140)
1
3
⁄8
(35)
2
1
⁄2
(64)
6
3
⁄4
(171)
2
5
⁄8
(67)
180 (HP)
200 (HP)
240 (HP)
300 (HP)
360 (HP)
420
All dimensions in inches (millimeters).
Hanging Spring Isolator
K
H
J
K
H
J1
Mounting Style A
Mounting Style B
Hanging Neoprene Isolator
Mounting Style A Mounting Style B
H
J
H
J1
Standing Spring Isolator
I
H
J
5/8 inch
(16mm)
nominal
5/8 inch
(16mm)
nominal
I
H
J1
Mounting Style A Mounting Style B
Standing Neoprene Isolator
L
H
J
Mounting Style A
L
H
J1
Mounting Style B
