Greenheck PVF User Manual

Indirect Gas-Fired Heat Modules 15
Performance Data
Supply Air Temperature Rise
Model
Input
(BTU/hr)
20°F 30°F 40°F 50°F 60°F 70°F 80°F 90°F 100°F
CFM
50 50,000
1852 1235 926 741 617 529 463 412 370
75 75,000
2778 1852 1389 1111 926 794 694 617 556
100 100,000
3704 2469 1852 1481 1235 1058 926 823 741
125 125,000
4630 3086 2315 1852 1543 1323 1157 1029 926
150 150,000
5556 3704 2778 2222 1852 1587 1389 1235 1111
175 175,000
6481 4321 3241 2593 2160 1852 1620 1440 1296
200 200,000
7407 4938 3704 2963 2469 2116 1852 1646 1481
225 225,000
8333 5556 4167 3333 2778 2381 2083 1852 1667
250 250,000
9259 6173 4630 3704 3086 2646 2315 2058 1852
275 275,000
10185 6790 5093 4074 3395 2910 2546 2263 2037
300 300,000
11111 7407 5556 4444 3704 3175 2778 2469 2222
325 325,000
12037 8025 6019 4815 4012 3439 3009 2675 2407
350 350,000
12963 8642 6481 5185 4321 3704 3241 2881 2593
400 400,000
14815 9877 7407 5926 4938 4233 3704 3292 2963
Sequence of Operation
Start-Up / Standby
Prior to start-up, verify that all field-installed sensors
have been installed. This includes a room temperature
sensor (optional) and a discharge air temperature sensor
(typical).
Heat Mode
When the unit or furnace controller calls for heat:
1. The ignition control will check that the pressure
switch for the combustion blower is open.
2. The combustion blower will energize and the
15second pre-purge begins.
3. The gas valve is energized and the igniter will spark
for up to 10 seconds. If a flame is not sensed during
the trial for ignition, two additional tries will be
attempted before going into lockout for one hour.
4. When a flame is sensed, sparking stops immediately.
The gas valve and combustion blower remain
energized.
5. Ignition
4:1 Electronic Modulation - The burner will light at
100% fire and remain there for up to 30 seconds.
The main burner gas valve will then modulate from
100% down to a minimum of 25%, as needed.
The combustion blower will change between high
and low speed to maintain acceptable combustion
airflow. If the high speed pressure switch does not
pull in when required, the furnace will lock out.
8:1 Stage Control - The furnace controller will ignite
the necessary manifolds at 100% for 30 seconds,
after which the unit or furnace controller will operate
the manifolds at high and low fire. Each time a
manifold is initialized, the manifold will ignite at
100%.
Single Stage Control - The burner will light at
100% and remain at high fire.
Two Stage Control - The burner will light at 100%
fire and remain there for 10 seconds. The unit or
furnace controller will operate the burners at either
high or low fire, depending on the demand for heat.
6. The ignition control constantly monitors the call for
heat, the pressure switch and the burner flame to
assure proper operation.
7. When the unit or furnace controls are satisfied,
the main gas valve is then de-energized and the
combustion blower shuts off following a 30 second
post-purge period.
Recovery from Lockout
If the furnace goes into lockout, the ignition control will
automatically reset after one hour if the thermostat is
still calling for heat. If needed, a manual reset can be
accomplished by either shutting off the power or turning
off the call for heat (turn off the thermostat) for a period
of five seconds.
®
